injection blow moulding machine

1 It adopts only one girder for the injection and blowing positions. there will be more space on the work table, and then it is easy to install the moulds. the core rod’s gyration semidiameter is more then before, now the products’ height is increased to 175mm. 2It’s hydraulic system adopts the Proportional Electro-Hydraulic Load Sensing Piston Pumps-Single Pump, it is energy-saving, high-efficiency. There is less return oil, when there is no load in the hydraulic system, oil temperature will be low, it can protect the hydraulic oil. 3 Injection clamping moulding section’s structure is improved, to ensure it can lock the injection mould better 4The work table is cast by ductile cast iron, and it is more thick, more strong and more steady. 5Figure is be improved, it will be hold much less space, and is looks nice NOITEMUNITIBM25IBM35IBM45IBM601Diameter of screw MM354045502Injection weight G1461762412803Heating capacity KW6.566.51010.84Control area of electric-heating QTY333-5Clamping force of injection KN2803504506006clamping force of blow KN303078897Opening stroke of mold platen MM1201201208injector stroke MM2002202002009Max. plate size of die(L*W) MM350*200420*300580*390740*39010Min. die. thickness(H) MM18018024028011Motor power KW1515223012Heating capacity of mould KW2.53.63.6613Pressure of hydraulics system MPA1414141414Min. working pressure of comp air MPA0.80.80.81.015Discharge rate of compressed air M3/min>=0.8>=0.8>=0.8>=0.816Consumption of cooling water M3/hr333517Dimension of machine (L*W*H) MM3100*1100*22003100*1100*22004000*1970*23504200*1340*235018Machine weight T2.53.066.819Suitable bottle Range L0.003-0.60.003-0.60.005-0.80.005-0.4520Max. Height of bottle MM<=145<=145<=200<=20021Max. dia. of the bottle MM<=100<=100<=100<=6022Conveyer belt motor power KW0.10.10.1-23Total power KW25253540
