injection blow moulding machine

1 It adopts only one girder for the injection and blowing positions. there will be more space on the work table, and then it is easy to install the moulds. the core rod’s gyration semidiameter is more then before, now the products’ height is increased to 175mm. 2It’s hydraulic system adopts the Proportional Electro-Hydraulic Load Sensing Piston Pumps-Single Pump, it is energy-saving, high-efficiency. There is less return oil, when there is no load in the hydraulic system, oil temperature will be low, it can protect the hydraulic oil. 3 Injection clamping moulding section’s structure is improved, to ensure it can lock the injection mould better. 4The work table is cast by ductile cast iron, and it is more thick, more strong and more steady. 5Figure is be improved, it will be hold much less space, and is looks nice. NoNameUnitDataNo.NameUnitData1screw stem diametermm4017Stripping distancemm1202Length/diameter ratio of screw stem (L/D)2018Mould sizeL ×Wmm400x2003Max. theoretical injection capacitycm318619Min. mould thicknessmm1804Injection volumeg18620Main motor powerkw155Max. injection pressureMPa15021Mould heating powerkw6Max. theoretical injection speed ratiocm3/sec.6022Hydraulic system pressureMPa147Max. distance of screwmm16523Lifting height of rotary tablemm608Twisting force of screw stemN.m51024displacement of compressed airM3/min0.89Rotary speed of screw stemrpm10-18025Pressure of compressed air systemMPa1.210Plasticizing capacityg/s1326Cooling consuming volumeM3/h311Electric heating power of cylinderkw6.527Overall sizeL× W× Hmm3100x1100x220012Electric heating control sectionqty328Machine weightT3.513Injection clamping mouldingkn28029Product scaleL0.005-0.614Opening distance of injection mouldmm12030Product heightmm≤17515Blow mouldingkn3031Product diametermm≤10016Opening distance of blow mouldingmm12032Central height of core barmm140
